Robin FL-H7500 - XI. AIR CLEANER CLEANING; Interval of Cleaning and Inspection: Daily (every 10 operating hours)

63


  
NO. Partname Instructions
1
 
IntervalofCleaningandInspection:Daily(every10operatinghours) 
(1) LoosentheKNOBBOLT.
(2) RemovetheCOVER,AIRCLEANER.
(3) TakeouttheELEMENTandremoveanydirtwiththebrush.
NOTE:TheELEMENTisadrytypeandshouldnotgetwet.Neverwash
withwater.
(4) ReplacetheELEMENTwithanewoneifitisdamagedorverydirty.
(PartNo.6676500201:ELEMENT,AIRCLEANER)
(5) Wipeoffanyoilthathascomeintocontactwiththebreatherwitha
ragorcloth.
(6) InstalltheELEMENTinthecleanercase.
(7) AttachtheCOVER,AIRCLEANERandtightentheKNOBBOLT.


ⅩⅠ．AIRCLEANERCLEANING
ELEMENT
KNOBBOLT

COVER,AIRCLEANER
BLEATHER

