２）Reassembly
 （１）RuntheSTARTERROPEthroughthe
        STARTERKNOBandmakeanoverhand
        knotasshowninFig.6-3.Run
        theSTARTERKNOBatitsopposite
        sidefromtheSTARTERCASEtothe
        REEL,makeaknotinthesameway,
        andputtheROPEendcompletely
        intheROPEHOUSINGoftheREEL.
        Then,applyasmallamountof
        greaseovertheSTARTERSHAFT
        andSPIRALSPRING.
 （２）MakesurethattheSPIRALSPRING
        isfitcompletelyinthespring
        grooveoftheREEL.FormtheSPRING
        endtohave1to2mmclearance
        betweentheSPIRALSPRINGinner
        endandREELBUSHsothatthe
       STARTERSHAFTcanhookontheHOOK
       securelyasshowninFig.6-4.
       TheSPIRALSPRINGinnerportion
       (about10cm-longfromtheend)
       canbechargedinshape.
 （３）BeforeinsertingtheREELinthe
        STARTERCASE,windtheSTARTER
        ROPEaroundtheREELthreeturns
        inthedirectionofthearrowshown
        inFig.6-5,drawoutthethirdturn
        oftheSTARTERROPEfromtheREEL
        ct-out,andfittheREELcompletely
        insidetheSTARTERCASEsothat
        theSPIRALSPRINGinnerendcanhook
        onthehook. Then,holdthe
        STARTERROPEasshowninFig.6-5,
        andtwisttheREEL4to5turns
        inthedirectionofthearrowusing
        theREELcut-out.Afterthecompletion
        ofwinding,oftheSTARTERROPE
        holdtheREELtightlytoprevent
        theSTARTERROPEfromwindingback,
        pulltheSTARTERKNOBinorderfor
        theSPIRALROPEtotightenandthen
        releasetheSTARTERKNOBslowly.
        Reassemblethepartsinreverse
        orderofdisassemblyshownin
        Fig.6-2.TightentheSETSCREW
        firmly.
 ※Besuretoperformthefollowing
    procedureinordertomakesure
    thatthepartshavebeenfit
    completely.





   
  


Fig.6-5
Fig.6-4
SPIRALSPRINGEND

SPIRALSPRING
INNER
END

HOOK
STARTERSH
AFT

REEL

Fig.6-3
