Robin RGV7500 Service Manual

- 2 -
DC OUTPUT
DC Voltage ................. 12 V
DC Ampere ................ 8.3 A
DC output................... 100 W
The voltage curve shown in the left indicates the characteristic of DC output when charging a battery.
The voltage may be decreased by 20% when the resistance load is applied.
NOTE : It is possible to use both DC and AC outputs simultaneously up to the rated output in total.
2. PERFOMANCE CURVES
Hz
(
Hz
)
(
V
)
(
125
)
63
250
(
120
)
240
(
115
)
230
(
110
)
220
62
61
60
60Hz
0 1/2 4/4
Load Rated
240V/120V
Hz
(
Hz
)
(
V
)
(
120
)
53
240
(
125
)
250
(
115
)
230
(
110
)
220
(
105
)
210
52
51
50
50Hz
0 1/2 4/4
Load Rated
220V/110V
240V
