Robin RGV7500 Service Manual

- 5 -
4-2 CONTROL PANEL
PILOT LAMPVOLTMETER
AC RECEPTACLE
KEY SWITCH
(ELECTRIC
STARTER TYPE)
ENGINE SWITCH
(RECOIL STARTER TYPE)
DC CIRCUIT BREAKER
DC OUTPUT
TERMINAL
NO-FUSE BREAKER
PILOT LAMP
AC RECEPTACLE
DC CIRCUIT BREAKER
DC OUTPUT
TERMINAL
NO-FUSE BREAKER
VOLTMETER
KEY SWITCH
(ELECTRIC
STARTER TYPE)
ENGINE SWITCH
(RECOIL STARTER TYPE)
* 50Hz-110V, 60Hz-110V, 60Hz-120V
* 50Hz-220V, 230V, 240V, 60Hz-220V
