10-4-3 REASSEMBLY
(1) Install the receptacles, no-fuse breaker, terminals, switches, etc. on the control panel and wire them.
NOTE : Circuit diagrams are shown in Section 12. Colored wires are used for easy identification, and are
of the correct capacity and size. Use heat-resistant type wires (permissible temperature range
75
°
C or over) in the specified gauge shown in the circuit diagrams.
(2) Connect the wires of control panel components.
(3) Attach the control panel to the control box.
M4 screw . . . 8 pcs.
