Maintenance 4-19

1502-UM051E-EN-P – June 2013

Table 4.A – Dimension “A” Settings in Inches (millimeters in brackets)

EXISTING NEW ALTITUDE RANGE

ALTITUDE Increase or Decrease Dimension “A” by:

RANGE 0-1000 m 1000-2000 m 2000-3000 m 3000-4000 m 4000-5000 m

0-1000 m N/A +0.073 (1.85) +0.140 (3.56) +0.194 (4.93) +0.246 (6.25)

1000-2000 m -0.073 (-1.85) N/A +0.067 (1.70) +0.121 (3.07) +0.173 (4.39)

2000-3000 m -0.140 (-3.56) -0.067 (-1.70) N/A +0.054 (1.37) +0.106 (2.69)

3000-4000 m -0.194 (-4.93) -0.121 (-3.07) -0.054 (-1.37) N/A +0.052 (1.32)

4000-5000 m -0.246 (-6.25) -0.173 (-4.39) -0.106 (-2.69) -0.052 (-1.32) N/A

  0OUIFSBUJOHMBCFMDIBOHFUIFDBUBMPHOVNCFSBMUJUVEFTVċYUIFTUBUFE

BMUJUVEFSBOHFBOEUIFDVSSFOUSBUJOH3FGFSUP5BCMF#GPSUIFEFSBUFE

DPOUJOVPVTDVSSFOUBOE#*-XJUITUBOESBUJOHTGPSFBDIBMUJUVEFSBOHF

"DPOUBDUPSXJMMPOMZGVODUJPOQSPQFSMZJOUIFBMUJUVEFSBOHF

for which it is set up. If functional tests are required, they

must be performed at the proper altitude or in a pressure

chamber which simulates the proper altitude.

A T T E N T I O N

Table 4.B – Contactor Deratings

Altitude Range

Continuous

Current Rating

B.I.L. Withstand

Rating

0-1000 m 800 A 60 kV

1000-2000 m 780 A 54 kV

2000-3000 m 760 A 48 kV

3000-4000 m 740 A 42 kV

4000-5000 m 720 A 36 kV

Rockwell Automation Allen-Bradley 1502 User Manual
