6-2 Renewal Parts
1502-UM051E-EN-P – June 2013
Table 6.A – Renewal Parts
Item Description of Parts Part Number
1 Three (3) Vacuum Bottles 80157-496-56
Series D 80025-697-01
2
Closing and Hold-in
Coil Assembly
Series E 80026-231-02
General 700-CPM
3
Master Contact
Cartridge
IntelliVAC or IntelliVAC Plus
feedback – Series E
700-CP1
Series D 80157-305-51
Electrically Held
Series E 80158-870-51
Series D 80157-305-52
4 Auxiliary Assembly
Mechanical Latch
Series E 80158-870-52
5 6-pole Terminal Block Assembly (high density) 1492-HC6
5A 6-pole Terminal Block Assembly (regular) 1492-HJ86
6 Control Wire Connector (Female only) 22105-221-01
7 Interphase Barrier 80157-311-01
8 Barrier Retainer 80157-312-01
9 Load Terminal 80157-315-02
10 Insulator 80157-314-01
11 Overtravel Spring 80026-012-02
12 Return Spring 80026-011-02
13 Rocker Washer 80012-021-01
14 Auxiliary Operating Lever 80157-313-02
15 Cam Follower 80154-422-01
16 One (1) MOV 80145-581-08
17 One (1) Rectifier Bridge (not shown) 24808-451-01
18 Mechanical Latch Trip Coil 80025-853-01
19 Mechanical Latch Spring 80026-013-02
20 Brass Washer 28300-614-01
21 Mechanical Latch Roller 80153-748-01
22 Mechanical Latch Refurbishing Kit 80158-058-51
Notes:
Rockwell Automation recommends that if the contactor has been in service, all three (3) bottles should be
replaced at the same time.
Refer to Figure 4.4.
Refer to Figure 4.28.
Refer to Figure 4.15 to 4.19.
Do not install washer if it was not originally supplied.
