Rockwell Automation Publication ENET-IN002H-EN-P - August 2017 35
Install a 1769 EtherNet/IP Adapter Chapter 3
System Configuration
Follow these rules when planning your system configuration.
The adapter must be the first and left-most module in the system (the first
module of Bank 1). See page 36
for an example configuration.
The adapter can communicate with up to 30 modules in a system that is
distributed across three I/O banks.
An end cap/terminator must be on the last I/O bank.
Each bank of I/O must have its own power supply.
A bank of I/O can have a maximum of 16 modules with a maximum of
eight on either side of the power supply, depending upon module loading
on the supply.
A 1769 I/O power supply has limits in the amount of 5V DC and
24V DC current it can supply to the modules in its I/O bank. These limits
depend on the catalog number (for example, 1769-PA2) of the supply. A
bank of modules should not exceed the current limits of the I/O bank
power supply. See the Compact 1769 Expansion I/O Power Supplies
Installation Instructions, publication 1769-IN028
.
The maximum amount of current the system supports in one direction
(either side of the power supply) is: 2 A @ 5V DC, 1 A @ 24V DC.
If another bank of I/O is required due to module requirements or I/O
loading, you can use a cable to link them together. You can have a
maximum of three banks of I/O connected with up to two
communication cables.
Each module type has its own distance rating (the number of modules
from the power supply). Each module must be within this rating for its
type.
The adapter has a distance rating of five, therefore the adapter must be
within five modules of the power supply.
