Chapter 3 I/O Memory Mapping
+ Local:1:I.Ch4_5Status SINT Binary
Local:1:I.Ch4OverRange BOOL Decimal
Local:1:I.Ch4UnderRange BOOL Decimal
Local:1:I.Ch4InHold BOOL Decimal
Local:1:I.Ch5OverRange BOOL Decimal
Local:1:I.Ch5UnderRange BOOL Decimal
Local:1:I.Ch5InHold BOOL Decimal
+ Local:1:I.Ch6_7Status SINT Binary
Local:1:I.Ch6OverRange BOOL Decimal
Local:1:I.Ch6UnderRange BOOL Decimal
Local:1:I.Ch6InHold BOOL Decimal
Local:1:I.Ch7OverRange BOOL Decimal
Local:1:I.Ch7UnderRange BOOL Decimal
Local:1:I.Ch7InHold BOOL Decimal
+ Local:1:I.Ch0ReadBack INT Decimal
+ Local:1:I.Ch1ReadBack INT Decimal
+ Local:1:I.Ch2ReadBack INT Decimal
+ Local:1:I.Ch3ReadBack INT Decimal
+ Local:1:I.Ch4ReadBack INT Decimal
+ Local:1:I.Ch5ReadBack INT Decimal
+ Local:1:I.Ch6ReadBack INT Decimal
+ Local:1:I.Ch7ReadBack INT Decimal
Tag
Name
Bit Indicates This
(1)
7 6543 210
Combined
Status
Ch7
Status
Ch6
Status
Ch5
Status
Ch4
Status
Ch3
Status
Ch2
Status
Ch1
Status
Ch0
Status
Module
Status
Power
Fail
Ch0_1
Status
Ch1
InHold
Ch1
Under
Range
Ch1
Over
Range
Ch0
InHold
Ch0
Under
Range
Ch0
Over
Range
Ch2_3
Status
Ch3
InHold
Ch3
Under
Range
Ch3
Over
Range
Ch2
InHold
Ch2
Under
Range
Ch2
Over
Range
Ch4_5
Status
Ch5
InHold
Ch5
Under
Range
Ch5
Over
Range
Ch4
InHold
Ch4
Under
Range
Ch4
Over
Range
Ch6_7
Status
Ch7
InHold
Ch7
Under
Range
Ch7
Over
Range
Ch6
InHold
Ch6
Under
Range
Ch6
Over
Range
(1) Bit positions left blank in table are always set to 0.
- Local:1:I AB:1769_OF8V:I:0
