146 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
Channel Configuration Words
The first two words of each eight word group in the configuration file allow you
to change the parameters of each channel independently. For example, words 8
and 9 correspond to channel 1 while words 56 and 57 correspond to channel 7.
Controller Tags for RSLogix 5000, Version 15 or Later
Use the following controller tags with RSLogix 5000, version 15 or later.
Define Indicate this These bit settings
1514131211109876543210
Program (Idle)
to Fault Enable
Program (Idle)
Mode Data
Applied
(1)
(1) These functions are not supported by all controllers, such as MicroLogix 1500, using any configuration method.
Refer to your controller manual for details.
0 0 0 0 0 0 0 0 0
Fault Mode Data
Applied
(1)
00000000 1
Hold for
Initialization
Disabled
0 0 0 0 0 0 0 0 0
Enabled 00000000 1
Program (Idle)
Mode
Hold Last State
(1)
0 0 0 0 0 0 0 0 0
User-Defined
Value
(1)
00000000 1
Fault Mode Hold Last State
(1)
0 0 0 0 0 0 0 0 0
User-Defined
Fault Value
(1)
00000000 1
Enable
Ramping
Disabled 0 0 0 0 0 0 0 0 0
Enabled 00000000 1
System
Interrupt High
Clamp
Disabled 0 0 0 0 0 0 0 0 0
Enabled 00000000 1
System
Interrupt Low
Clamp
Disabled 0 0 0 0 0 0 0 00
Enabled 0 0 0 0 0 0 0 01
Enable Channel Disabled 0 0 0 0 0 0 0 0 0
Enabled 100000000
Define Indicate this These bit settings
1514131211109876543210
Output
Range
Select
0 to 20 mA dc 0 0 0 0 0 0 0 0 0 0000
4 to 20 mA dc
0 0 0 0 0 0 0 0 0 0001
Output
Data
Select
Raw/Proportional
Counts
0 0 0 0 0 0 0 0 0 0 0 0 0
Engineering Units 0 0 0 0 00010 0 0 0 0
Scaled for PID 0 0 0 0 00100 0 0 0 0
Percent Range 0 0 0 0 00110 0 0 0 0
To Next Page
