Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 147
I/O Memory Mapping Chapter 3
Channel 0 and 1 Configuration Data
Channel 0 and 1 configuration data is shown below. The same information
applies to all channels.
- Local:1:C AB:1769_OF8C:C:0
Local:1:C.Ch0ProgToFaultEn BOOL Decimal
Local:1:C.Ch0HoldForInit BOOL Decimal
Local:1:C.Ch0ProgMode BOOL Decimal
Local:1:C.Ch0FaultMode BOOL Decimal
Local:1:C.Ch0RampEn BOOL Decimal
Local:1:C.Ch0AlarmLatchEn BOOL Decimal
Local:1:C.Ch0OverRangeInterruptEn BOOL Decimal
Local:1:C.Ch0UnderRangeInterruptEn BOOL Decimal
Local:1:C.Ch0En BOOL Decimal
+ Local:1:C.Ch0Range SINT Decimal
+ Local:1:C.Ch0DataFormat SINT Decimal
+ Local:1:C.Ch0FaultValue INT Decimal
+ Local:1:C.Ch0ProgValue INT Decimal
+ Local:1:C.Ch0LClampValue INT Decimal
+ Local:1:C.Ch0HClampValue INT Decimal
+ Local:1:C.Ch0RampRate INT Decimal
Local:1:C.Ch1ProgToFaultEn BOOL Decimal
Local:1:C.Ch1HoldForInit BOOL Decimal
Local:1:C.Ch1ProgMode BOOL Decimal
Local:1:C.Ch1FaultMode BOOL Decimal
Local:1:C.Ch1RampEn BOOL Decimal
Local:1:C.Ch1AlarmLatchEn BOOL Decimal
Local:1:C.Ch1OverRangeInterruptEn BOOL Decimal
Local:1:C.Ch1UnderRangeInterruptEn BOOL Decimal
Local:1:C.Ch1En BOOL Decimal
+ Local:1:C.Ch1Range SINT Decimal
+ Local:1:C.Ch1DataFormat SINT Decimal
+ Local:1:C.Ch1FaultValue INT Decimal
+ Local:1:C.Ch1ProgValue INT Decimal
+ Local:1:C.Ch1LClampValue INT Decimal
+ Local:1:C.Ch1HClampValue INT Decimal
+ Local:1:C.Ch1RampRate INT Decimal
