Chapter 3 I/O Memory Mapping
Tag Name To Select Make These Bit Settings
(1)
15…
8
76543210
Ch#ProgToFaultEn Enable 1
Disable 0
Ch#HoldForInit Enable 1
Disable 0
Ch#ProgMode Enable 1
Disable 0
Ch#FaultMode Enable 1
Disable 0
Ch#RampEn Enable 1
Disable 0
Ch#AlarmLatchEn Enable 1
Disable 0
Ch#OverRangeInterruptEn Enable 1
Disable 0
Ch#UnderRangeInterruptEn Enable 1
Disable 0
Ch#En Enable 1
Disable 0
Ch#Range 0…20 mA dc 0
4…20 mA dc 1
Ch#DataFormat Raw/proportional
counts
00
Engineering units 0 1
Scaled for PID 1 0
Percent range 1 1
(1) All bit positions left blank in table must be set to 0.
