I/O Memory Mapping Chapter 3
The bits are defined as follows:
• Shaded bit positions must be set to 0.
• Input filter: Real input point filter selection. See page 190
.
• EI_Ix: Enable input interrupt; 1 = interrupt enabled, 0 = interrupt
disabled.
• IT_Ix: Input interrupt type; 1 = generate interrupt on real input point
transition from on to off, 0 = generate interrupt on real input point
transition from off to on.
• PFE: Program to fault enable; 1 = fault value applied, 0 = program value
applied.
• PMx: Program mode; 1 = hold last state, 0 = user-defined safe state.
• PVx: Program value; 1 = output on, 0 = output off.
• FMx: Fault mode; 1 = hold last state, 0 = user-defined safe state.
• FVx: Fault value; 1 = output on, 0 = output off.
• DB_x: Output Control; 1 = output in Direct Control mode, 0 = output
in BOOLEAN Control mode.
21 Output Delay 1
22 Output Duration 1
23
24 IT_O2 EI_
O2
DB
_1
25 Operand_A_2
26
Operand_B_2
27 Operand_C_2
28 Operator
_2_2
Operator
_1_2
29
Output Delay 2
30 Output Duration 2
31
32 IT_O3 EI_
O3
DB
_3
33 Operand_A_3
34 Operand_B_3
35
Operand_C_3
36 Operator
_2_3
Operator
_1_3
37 Output Delay 3
38
Output Duration 3
39
Word
Bit Position
1514131211109876543210
