Chapter 3 I/O Memory Mapping
12 S Alarm Dead Band Value Channel 1
13 Pad
14 EC Reserved EA AL EI Reserved Input Filter Sel Chl2
15 Reserved Inpt Dta Fm
Chl2
Reserved Inpt Tp/RngeSel Chl2
16 S Process Alarm High Data Value Channel 2
17 S Process Alarm Low Data Value Channel 2
18 S Alarm Dead Band Value Channel 2
19 Pad
20 EC Reserved EA AL EI Reserved Input Filter Sel Chl3
21 Reserved Inpt Dta Fm
Chl3
Reserved Inpt Tp/RngeSel Chl3
22 S Process Alarm High Data Value Channel 3
23 S Process Alarm Low Data Value Channel 3
24 S Alarm Dead Band Value Channel 3
25 Pad
26 EC Reserved EA AL EI Reserved Input Filter Sel Chl4
27 Reserved Inpt Dta Fm
Chl4
Reserved Inpt Tp/RngeSel Chl4
28 S Process Alarm High Data Value Channel 4
29 S Process Alarm Low Data Value Channel 4
30 S Alarm Dead Band Value Channel 4
31 Pad
32 EC Reserved EA AL EI Reserved Input Filter Sel Chl5
33 Reserved Inpt Dta Fm
Chl5
Reserved Inpt Tp/RngeSel Chl5
34 S Process Alarm High Data Value Channel 5
35 S Process Alarm Low Data Value Channel 5
36 S Alarm Dead Band Value Channel 5
37 Pad
38 EC Reserved EA AL EI Reserved Input Filter Sel Chl6
39 Reserved Inpt Dta Fm
Chl6
Reserved Inpt Tp/RngeSel Chl6
40 S Process Alarm High Data Value Channel 6
41 S Process Alarm Low Data Value Channel 6
42 S Alarm Dead Band Value Channel 6
43 Pad
44 EC Reserved EA AL EI Reserved Input Filter Sel Chl7
45 Reserved Inpt Dta Fm
Chl7
Reserved Inpt Tp/RngeSel Chl7
46 S Process Alarm High Data Value Channel 7
Word
Bit Position
15 14131211109876543210
