Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 83
I/O Memory Mapping Chapter 3
32 EC Reserved EA AL EI
(1)
Reserved Input Filter Sel Ch5
33 Reserved Input Data
Format Ch5
Reserved Input Type/Range
Select Ch5
34 SGN Process Alarm High Data Value Channel 5
35 SGN Process Alarm Low Data Value Channel 5
36 SGN Alarm Dead Band Value Channel 5
37 Reserved
38 EC Reserved EA AL EI
(1)
Reserved Input Filter Sel Ch6
39 Reserved Input Data
Format Ch6
Reserved Input Type/Range
Select Ch6
40 SGN Process Alarm High Data Value Channel 6
41 SGN Process Alarm Low Data Value Channel 6
42 SGN Alarm Dead Band Value Channel 16
43 Reserved
44 EC Reserved EA AL EI
(1)
Reserved Input Filter Sel Ch7
45 Reserved Input Data
Format Ch7
Reserved Input Type/Range
Select Ch7
46 SGN Process Alarm High Data Value Channel 7
47 SGN Process Alarm Low Data Value Channel 7
48 SGN Alarm Dead Band Value Channel 7
49 Reserved
50 EC Reserved EA AL EI
(1)
Reserved Input Filter Sel Ch8
51 Reserved Input Data
Format Ch8
Reserved Input Type/Range
Select Ch8
52 SGN Process Alarm High Data Value Channel 8
53 SGN Process Alarm Low Data Value Channel 8
54 SGN Alarm Dead Band Value Channel 8
55 Reserved
56 EC Reserved EA AL EI
(1)
Reserved Input Filter Sel Ch9
57 Reserved Input Data
Format Ch9
Reserved Input Type/Range
Select Ch9
58 SGN Process Alarm High Data Value Channel 9
59 SGN Process Alarm Low Data Value Channel 9
60 SGN Alarm Dead Band Value Channel 9
61 Reserved
62 EC Reserved EA AL EI
(1)
Reserved Input Filter Sel Ch10
63 Reserved Input Data
Format Ch10
Reserved Input Type/Range
Select Ch10
64 SGN Process Alarm High Data Value Channel 10
65 SGN Process Alarm Low Data Value Channel 10
66 SGN Alarm Dead Band Value Channel 10
Word
Bit Position
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
