Rockwell Automation Allen-Bradley 1769-OF4 Installation Instructions

194 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
Word
Bit Position
(1)
1514131211109876543210
13, 21,
29, 37
Output
Delay 0
0 ms 0000000000
1 ms 0000000001
Output
Delay 1
2 ms
0000000010
3 ms 0000000011
Output
Delay 2
4 ms 0000000100
5 ms
0000000101
Output
Delay 3
6 ms 0000000110
7 ms 0000000111
…
993 ms 1111100001
994 ms 1111100010
995 ms
1111100011
996 ms 1111100100
997 ms 1111100101
998 ms
1111100110
999 ms 1111100111
1000 ms 1111101000
(1) Shaded bit positions must be set to 0. Entering a binary value greater than 1111101000 (greater than 1000
decimal) results in a configuration error.
