36 Rockwell Automation Publication 440R-UM010C-EN-P - September 2016
Appendix A Specifications
Inputs IN1
Lock Unlock Request
Attribute 440R-GL2S2T
Input Signals (Active High) S12, S22
Input Simultaneity Infinite
ON Voltage, Max 26.4V
ON Voltage, Min 11V
OFF Voltage, Max 5V
OFF Current, Max 2 mA
ON Current at 24V DC, Max 11 mA
ON Current at 26.4V DC, Max 11.1 mA
Galvanic Isolation: I/O from Logic No
Overvoltage Protection Yes
Test Out Pulse Duration 700 µs
Test Out Pulse Period 17 ms
Off Pulse accepted for OSSD setting
without declaring the input as OFF
Min = 0 µs
Max = 700 µs
Reverse Voltage Protection Yes
Input Capacitance 10 nF
Attribute 440R-GL2S2T
Input Signals (Active High) S44, S54
ON Voltage, Max 26.4V
ON Voltage, Min 11V
OFF Voltage, Max 5V
OFF Current, Max 2 mA
ON Current at 24V DC, Max 11 mA
ON Current at 26.4V DC, Max 11.1 mA
Galvanic Isolation: I/O from Logic No
Overvoltage Protection Yes
Input Capacitance 10 nF
Duration 0.5…3.0 s
