Rockwell Automation Allen-Bradley 440R-GL2S2T

Rockwell Automation Publication 440R-UM010C-EN-P - September 2016 37
Specifications Appendix A
Retrigger
Outputs
Attribute 440R-GL2S2T
Input Signal (Active High) B2
ON Voltage, Max 26.4V
ON Voltage, Min 11V
OFF Voltage, Max 5V
OFF Current, Max 2 mA
ON Current at 24V DC, Max 11 mA
ON Current at 26.4V DC, Max 11.1 mA
Galvanic Isolation: I/O from Logic No
Overvoltage Protection Yes
Input Capacitance 10 nF
Attribute 440R-GL2S2T
Number of Outputs 4
Output Signals (Active High) S11, S21, 14, and 24
Continuous Output Current 0.5 A
Aggregate Current of Outputs per Module,
Max
1.8 A
Surge Output Current, Max 1.5 A
Surge Output Current Duration, Max 5 ms
Residual Voltage (Drop from Power
Supply), Max
0.2V
Max Load Capacitance 1 µF
Off State Leakage Current, Max < 0.1 mA
Short Circuit Protection Yes
Galvanic Isolation: I/O from Logic No
Pulse Test Duration
≤700 µs
Pulse Test Period ≤13000 ms (less than 15 s)
Maximum Resistance for the Auto
Detection of a Coil
10k
Maximum Resistance for the Auto
Detection of an LL Device
10k
