Rockwell Automation Publication 440R-UM010C-EN-P - September 2016 39
Specifications Appendix A
Single Wire Safety Output
Signal
Recovery Times
Response Times
Attribute 440R-GL2S2T
Output Signals L11
Continuous Output Current, Max 50 mA
ON State Voltage Drop (P/S to +), Max 0.2V
Surge Output Current, Max 700 mA
Surge Output Current Duration, Max 5 ms
Max Load Capacitance 1 µF
Off State Leakage Current, Max < 0.1 mA
Short Circuit Detection No
Short Circuit Protection Yes
Galvanic Isolation: I/O from Logic No
Logic 1…4 Logic 5…8
14, 24 L11 Cat 1 Y32 14, 4 L11 Cat1 Y32
Reset (S44) 26 ms 26 ms 23 ms 27 ms 28 ms 25 ms
Logic 1…4 Logic 5…8
14, 24 L11 Cat 1 Y32 14, 4 L11 Cat1 Y32
Unlock Request (S54) 32 ms 27 ms 32 ms — — —
Single Wire Safety Input, L12 48 ms 48 ms 49 ms 37 ms 35 ms 38 ms
Safety Inputs (S12, S22) 68 ms 61 ms 70 ms 55 ms 51 ms 57 ms
