Rockwell Automation Publication 5069-UM007A-EN-P - February 2019 13
Chapter 2
Compact 5000 EtherNet/IP Adapter Power
Requirements
The adapters provide power to I/O modules as follows:
• System-side power that powers the I/O modules and lets them transfer
data and execute logic.
System-side power is provided through the Module (MOD) Power
connector and is passed to each module as it is added to the system.
System-side power is also known as MOD power.
• Field-side power that powers some Compact 5000™ I/O modules and
field-side devices that are connected to them.
Field-side power is provided through the Sensor/Actuator (SA) Power
connector and is passed to each module as it is added to the system.
Field-side power is also known as SA power.
Power begins at the adapter and passes across the I/O module internal circuitry
via power buses. The MOD power bus and SA power bus are isolated from
each other.
Topic Page
Power Connectors 14
MOD Power Bus 15
SA Power Bus 16
