Rockwell Automation Publication 5069-UM007A-EN-P - February 2019 51
Module Tags Appendix B
HMIPacketRate DINT The number of Class 3 packets and unconnected packets that are sent and received by
the device in the previous second.
All
IOPacketRate DINT The number of class 0 and class 1 packets that are transmitted or received by the
adapter in the previous second.
All positive values
EthernetErrors DINT The sum over all ports of the Ethernet Link object values: In Discards, In Errors, In
Unknown Protos, Out Discards, Out Errors, Alignment Errors, FCS Errors, Single
Collisions, Multiple Collisions, SQE Test Errors, Deferred Transmissions, Late Collisions,
Excessive Collisions, MAC Transmit Errors, Carrier Sense Errors, Frame Too Long, and
MAC Receive Errors.
All positive values
CPUUtilization INT The percentage of the capacity of the product's compute engine (whether that is a
CPU, or a core of a CPU, or a thread) most important to the performance of
communication of packets by the product. The value equals the percentage.
0…100
DLRNetworkState SINT The current value of the Network Status instance attribute of the DLR object for devices
with multiple Ethernet ports that support DLR.
0 - Normal
1 - Ring Fault
2 - Unexpected Loop Detected
3 - Partial Network Fault
4 - Rapid Fault/Restore Cycle
DLRSupervisorState SINT The current value of the Ring Supervisor Status instance attribute of the DLR object for
devices with multiple Ethernet ports that support DLR.
0 - Device is functioning as a backup
1 - Device is functioning as the active
ring supervisor
2 - Device is functioning as a normal ring
node
3 - Device is operating in a non-DLR
topology
4 - Device cannot support the current
ring parameters (Beacon Interval and
Beacon Timeout)
MemoryCardFault
This tag is only available with
the 5069-AEN2TR adapter.
BOOL Indicates if an SD card fault was detected. Either of the following conditions can trigger
the fault:
• When there is not an SD card in the SD card slot.
• When a corrupted write on SD card was detected.
0 - No fault
1 - SD card fault detected
MemoryCardDataMismatch
This tag is only available with
the 5069-AEN2TR adapter.
BOOL Indicates that there is a difference between the configuration that is stored on the
adapter and the configuration that is stored on the SD card.
0 - No fault
1 - SD card data mismatch detected
LocalClockOffset LINT The offset from the local clock to the system time. This value helps to detect steps in
time. This value updates when a PTP update is received.
All
LocalClockOffsetTimestamp LINT The time when the Local Clock Offset was sampled. This value is initially zero, and the
first time stamp occurs when the module synchronizes with the master clock.
—
GrandMasterClockID SINT[8] The EUI-64 Identity of the CIP Sync Grandmaster clock the module is synced to. All
Table 5 - 5069 Compact I/O EtherNet/IP Adapter Module Tags
Tag Name Data Type Definition Valid Values
