12 Rockwell Automation Publication 1492-QS003B-EN-P - October 2019
Chapter 1 Installation
Connect to a Computer or Computer Network
Use a USB or Ethernet port to connect the printer to your computer.
USB Installation
1. Start the ClearTools Software.
2. From the Tools menu, click Printer Administration>Printer Explorer.
3. Click Add to add the ClearMultiprint marking system.
The following dialog box appears.
4. Click USB to start the printer search.
The search result is displayed in the following dialog box.
5. If no printer was found, click Search to start the search process again.
6. If a printer was found, select the printer and click Add.
The following dialog box appears.
7. To change the printer name, click Properties.
