Publication 2711P-UM001D-EN-P - September 2005
Terminal Connections 6-13
DH+ Status Indicator
DH-485 Status Indicator
Remote I/O Scanner Mode Status Indicator
Condition Indication
off Channel is not online
blinking green Device is only node on the network.
solid green Device is online and receiving token.
blinking red Duplicate node
solid red Failed selftest
Condition Indication
off Channel is not online
blinking green Device is only node on the network.
solid green Device is online and receiving token.
blinking red Parity error
solid red Failed selftest
Condition Indication
off Channel is not online
blinking green At least one but not all adapters in
the scanlist are not responding.
solid green All adapters in the scanlist are
responding.
blinking red None of the adapters in the scanlist
are responding.
solid red Failed selftest
