Publication 2711P-UM001D-EN-P - September 2005
1-12 Overview
Catalog Number
Configuration
The table lists the catalog number configuration for the terminals.
PanelView Plus Product
Components
Components are available as separate catalog numbers for field
installation or replacement.
Display Modules (700 - 1500 only)
Input
Ty pe
Display
Size
Display Type Communications Power Memory
Flash/RAM
(1)
||| | | |
2711P- K = Keypad 4 = 3.8 inch C = Color PanelView Plus 400 and 600 Terminals A = AC 1= 64 MB/64 MB
T = Touch 6 = 5.5 inch M=Grayscale 1 = Remote I/O (single rack), ENet, RS-232 & USB
B = AC DIN
(1)
2 = 128 MB/128 MB
B = Key & Touch 7 = 6.5 inch 3 = DH-485, ENet, RS-232 & USB D = DC
10 = 10.4 inch 5 = RS-232 & USB
12 = 12.1 inch 8 = DH+, ENet, RS-232 & USB
15 = 15 inch 10 = DNet, ENet, RS-232 & USB
15 = CNet, ENet, RS-232 & USB
20 = ENet, RS-232 & USB
PanelView Plus 700 - 1500 Terminals
4 = ENet, RS-232 & (2) USB
6 = DH+, DH-485, RIO, ENet, RS-232 & (2) USB
10 = DNet, ENet, RS-232 & (2) USB
15 = CNet, ENet, RS-232 & (2) USB
(1)
Applies to PanelView Plus 700-1500 terminals only.
Cat. No. Description
2711P-RDK7C 700 Keypad Color Display
2711P-RDT7C 700 Touch Color Display
2711P-RDB7C 700 Keypad and Touch Color Display
2711P-RDK10C 1000 Keypad Color Display
2711P-RDT10C 1000 Touch Color Display
2711P-RDB10C 1000 Keypad and Touch Color Display
2711P-RDK12C 1250 Keypad Color Display
2711P-RDT12C 1250 Touch Color Display
2711P-RDT12CK Conformally Coated 1250 Touch Color Display
2711P-RDT12H 1250 Touch High-Bright Color Display
2711P-RDB12C 1250 Keypad and Touch Color Display
2711P-RDK15C 1500 Keypad Color Display
2711P-RDT15C 1500 Touch Color Display
2711P-RDB15C 1500 Keypad and Touch Color Display
