Terminal Connections 6-19
Minimum Requirements
The following software and firmware must be installed on the
development computer and the PanelView Plus terminal to configure
and communicate with an Allen-Bradley controller on a ControlNet
network.
ControlNet Unscheduled Communications
ControlNet Scheduled Communications
Software/Firmware PanelView Plus 700-1500 PanelView Plus 400 or 600
RSView Studio v3.10 or later v4.0 or later
RSView Machine Edition Runtime v3.10 or later v4.0 or later
ControlNet Module Firmware 2711P-RN15S, Series A, Rev A
(firmware v2.07 or later)
(1)
2711P-RN15C, Series B, Rev A
or later
(1)
This applies to terminals that are ordered as pre-configured units with the ControlNet module.
Requirements PanelView Plus 700-1500 PanelView Plus 400 or 600
RSView Studio v3.20 or later v4.0 or later
RSView Machine Edition Runtime v3.20.04 or later v4.0 or later
RSNetWorx for ControlNet v5.11 or later v6.0 or later
RSLogix 5000 v13.0 or later v15.0 or later
ControlNet Module Firmware 2711P-RN15S, Series A, Rev C
(firmware v3.08 or later)
(1)
2711P-RN15C, Series B, Rev A
or later
(1)
This applies to terminals that are ordered as pre-configured units with the ControlNet module.
WARNING
The ControlNet Communications Module
(2711P-RN15S) will not run with RSView ME
firmware 3.20.04 or earlier. All ControlNet Modules
with v3.07 firmware must be upgraded to v3.08 or
later; otherwise, outputs may turn on an
indeterminate state.
