Publication 2711P-UM001D-EN-P - September 2005
Overview 1-5
Displays and Input Options
PanelView Plus 400 and 600 terminals are available with these display
and operator input options:
• 400 terminals: 3.8 inch grayscale (320 x 240) graphics display
with keypad
• 600 terminals: 5.5 inch color or grayscale (320 x 240) graphics
display with keypad, touch screen, or keypad & touch support
Touch Screen
The PanelView Plus 600 terminals offer an analog resistive touch
screen allowing for flexible touch area configuration.
600 Color or Grayscale Terminals
with Touch Screen
IMPORTANT
Use a plastic stylus device with a minimum tip radius
of 1 mm (0.040 in) to prevent damage to the touch
screen.
