Chapter 1 Drive Selection Considerations
Table 4b- PowerFlex 700 Drive Catalog Number Explanation (continued)
Position
1 - 3
a
20B
4
b
D
5 - 7
c
2P1
8
d
A
9
e
3
10
f
A
11
g
Y
12
h
N
13
i
A
14
j
R
15
k
C
16
l
0
17 - 18
m
NN
19 - 20
n
AD
e
HIM
Code Operator Interface
0 Blank cover
3 Full numeric LCD
5 Prog. only LCD
J
(1)
(1) Only available with Frame 5 and Frame 6
stand-alone IP54 drives (enclosure code “G”).
Remote (panel mount)
IP66, NEMA/UL Type 12
Full numeric LCD HIM
K
(1)
Remote (panel mount)
IP66, NEMA/UL Type 12
Prog. only LCD HIM
f
Documentation
Code Type
A Manual
N No manual
Q No shipping package
(internal use only)
g
Brake
Code With Brake IGBT
(1)
(1) Brake IGBT is:
• standard on Frame 0…3 drives
• optional on Frame 4…6 drives
• not available on Frame 7…10 drives
YYes
NNo
i
Emission
(1)
(1) Refer to “Internal EMC Filter” in publication
20B-UM002
for details on selecting this option.
(2) 600V class drives below 77 Amps (Frames 0…4)
are declared to meet the Low Voltage directive.
The user is responsible for determining
compliance to the EMC directive.
Frames 7…10 400/480V AC drives (voltage rating
codes “C” and “D”) meet CE certification
requirements when installed per recommendations.
(3) Only available for 208…240V Frame 0…3 drives.
Code CE Filter
(2)
CM Choke
AYes Yes
B
(3)
Yes No
NNo No
j
Communication Slot
Code Network Type
BBACnet MS/TP
C ControlNet (Coax)
D DeviceNet
EEtherNet/IP
R Remote I/O
S RS485 DF1
NNone
k
Emission
Code Control I/O Volts
A Standard 24V DC/AC
B Standard 115V AC
C Vector
(1)
(1) Vector control options uses DPI only.
Frame 7…10 drives only accept vector control.
24V DC
D Vector
(1)
115V AC
N Standard None
l
Feedback
Code Type
0None
1 Encoder 12V/5V
n
Special Firmware
(1)
(1) Only available for Frame 0…6 drives.
Code Type
AD
(2)
(2) Must be used with vector control option “C” or
“D” (position “k”). Positions “m” and “n” are only
required when custom firmware is supplied.
60 Hz maximum
AE
(2)
Cascading fan/pump control
AX
(2)
82 Hz maximum
BA
(2)
Pump off (for pump jack)
m
For Future Use
Code Type
NN None
h
Internal Braking Resistor
Code With Resistor
(1)
YYes
NNo
(1) Not available for Frame 3 drives or higher.
To Next Page
