Appendix A
Permanent Magnet Motors
Allen-Bradley® servo motors are compatible with PowerFlex 755TS drives.
Compatible Allen-Bradley
Servo Motors
The following table is a list of specifications for Allen-Bradley servo motors
that compatible with PowerFlex 755TS drives. This information is provided to
help configure PowerFlex 750-Series drives with the appropriate servo motor
data. For information regarding compatibility and configuration of any
Allen-Bradley servo motors (including RDB Series Direct Drive Motors) and
third-party PM motors that are not listed here, contact Allen-Bradley Drives
Technical Support.
Table 4 - Motor Name Plate and Rating Specifications
Model Number
Motor NP Volts
[line to line V rms]
Motor NP Amps
[A rms]
Motor NP
Hertz [Hz]
Motor NP RPM
[oper. rpm]
Motor NP
Power [kW]
Motor
Poles
Current peak
[A rms]
System Cont. Stall
Torque [N•m]
Motor Max RPM
[rpm]
MPM-A1151M 240 4.2 333.3 5000 0.90 8 21.6 2.18 6000
MPM-A1152F 240 5.9 266.7 4000 1.40 8 31.7 4.74 5000
MPM-A1302F 240 7.4 266.7 4000 1.65 8 35.6 5.99 4500
MPM-A1304F 240 8.1 233.3 3500 2.20 8 34.2 9.30 4000
MPM-A1651F 240 14.5 200.0 3000 2.50 8 52.2 10.70 5000
MPM-A1652F 240 18.1 233.3 3500 4.03 8 73.0 13.50 4000
MPM-A1653F 240 23.2 200.0 3000 5.10 8 84.3 18.60 4000
MPM-A2152F 240 33.7 133.3 2000 5.20 8 89.0 27.00 4000
MPM-A2153F 240 32.8 133.3 2000 5.80 8 85.2 34.00 4600
MPM-A2154C 240 24.8 116.7 1750 6.50 8 89.8 55.00 2000
MPM-A2154E 240 29.6 133.3 2000 7.00 8 90.7 44.00 2650
MPM-B1151F 480 1.5 266.7 4000 0.75 8 7.0 2.18 5000
MPM-B1151T 480 3.1 333.3 5000 0.90 8 14.5 2.18 7000
MPM-B1152C 480 2.3 166.7 2500 1.20 8 8.8 2.18 3000
MPM-B1152F 480 2.9 266.7 4000 1.40 8 15.5 4.74 5200
MPM-B1152T 480 5.2 266.7 4000 1.40 8 26.8 4.74 7000
MPM-B1153E 480 2.7 200.0 3000 1.40 8 15.3 6.55 3500
MPM-B1153F 480 3.2 266.7 4000 1.45 8 22.6 6.55 5500
MPM-B1153T 480 5.5 266.7 4000 1.45 8 39.2 6.55 7000
MPM-B1302F 480 3.4 266.7 4000 1.65 8 15.6 5.99 4500
MPM-B1302M 480 5.0 266.7 4000 1.65 8 22.6 5.99 6000
MPM-B1302T 480 6.6 266.7 4000 1.65 8 30.7 5.99 7000
MPM-B1304C 480 3.4 183.3 2750 2.00 8 15.8 10.20 2750
MPM-B1304E 480 4.1 166.7 2500 2.20 8 24.2 10.20 4000
MPM-B1304M 480 7.3 233.3 3500 2.20 8 42.9 10.20 6000
MPM-B1651C 480 4.7 200.0 3000 2.50 8 20.6 10.70 3500
MPM-B1651F 480 8.2 200.0 3000 2.50 8 36.0 10.70 5000
MPM-B1651M 480 10.9 200.0 3000 2.50 8 40.2 10.70 5000
MPM-B1652C 480 7.0 166.7 2500 3.80 8 23.8 16.00 2500
MPM-B1652E 480 8.0 233.3 3500 4.30 8 42.8 19.40 3500
MPM-B1652F 480 11.0 233.3 3500 4.30 8 59.5 19.40 4500
MPM-B1653C 480 10.5 133.3 2000 4.60 8 41.9 26.80 2500
