Appendix A Permanent Magnet Motors
MPM-B1653E 480 10.2 200.0 3000 5.10 8 51.6 26.80 3500
MPM-B
1653F 480 13.2 200.0 3000 5.10 8 66.7 26.80 4000
MPM-B2152C 480 12.3 133.3 2000 5.60 8 39.2 36.70 2500
MPM-B2152F 480 18.7 166.7 2500 5.90 8 69.3 33.00 4500
MPM-B2152M 480 21.0 166.7 2500 5.90 8 54.0 30.00 5000
MPM-B2153B 480 12.7 116.7 1750 6.80 8 42.4 48.00 2000
MPM-B2153E 480 19.3 133.3 2000 7.20 8 69.7 48.00 3000
MPM-B2153F 480 22.1 133.3 2000 7.20 8 69.6 45.00 3800
MPM-B2154B 480 13.9 116.7 1750 6.90 8 69.3 62.80 2000
MPM-B2154E 480 18.3 133.3 2000 7.50 8 69.5 56.00 3000
MPM-B2154F 480 19.8 133.3 2000 7.50 8 59.3 56.00 3300
MPL-A310P 230 3.4 294.0 4410 0.73 8 9.9, 1.58 5000
MPL-A310F 230 2.1 185.3 2780 0.46 8 6.6 1.58 3000
MPL-A320P 230 6.4 271.3 4070 1.30 8 20.9 3.05 5000
MPL-A320H 230 4.6 208.7 3130 1.00 8 13.6 3.05 3500
MPL-A330P 230 8.5 280.7 4210 1.80 8 26.9 4.08 5000
MPL-A420P 230 9.0 268.7 4030 2.00 8 32.5 4.74 5000
MPL-A430P 230 11.9 234.0 3510 2.20 8 47.4 5.99 5000
MPL-A430H 230 8.6 184.7 2770 1.80 8 31.8 6.21 3500
MPL-A4520P 230 12.4 234.0 3510 2.20 8 35.4 5.99 5000
MPL-A4520K 230 10.6 223.3 3350 2.10 8 30.4 5.99 4000
MPL-A4530F 230 9.5 144.7 2170 1.90 8 29.7 8.36 2800
MPL-A4530K 230 14.4 196.0 2940 2.50 8 43.8 8.13 4000
MPL-A4540C 230 6.6 93.3 1400 1.50 8 20.5 10.20 1500
MPL-A4540F 230 13.0 162.0 2430 2.60 8 38.2 10.20 3000
MPL-A520K 230 16.3 208.0 3120 3.50 8 46.0 10.70 4000
MPL-A540K 230 29.3 180.7 2710 5.50 8 84.9 19.40 4000
MPL-A560F 230 29.3 125.3 1880 5.50 8 84.9 27.90 3000
MPL-B310P 460 1.7 310.0 4650 0.77 8 3.0 1.58 5000
MPL-B320P 460 3.2 313.3 4700 1.50 8 5.0 3.05 5000
MPL-B330P 460 4.3 274.0 4110 1.80 8 7.0 4.18 5000
MPL-B420P 460 4.5 255.3 3830 1.90 8 9.2 4.74 5000
MPL-B430P 460 6.5 214.0 3210 2.20 8 12.0 6.55 5000
MPL-B4520P 460 6.0 236.7 3550 2.10 8 17.0 5.65 5000
MPL-B4530F 460 5.0 162.0 2430 2.10 8 13.4 8.25 3000
MPL-B4530K 460 7.8 200.7 3010 2.60 8 19.1 8.25 4000
MPL-B4540F 460 6.4 162.0 2430 2.60 8 16.3 10.20 3000
MPL-B4560F 460 8.3 144.7 2170 3.20 8 25.5 14.10 3000
MPL-B520K 460 8.1 208.0 3120 3.50 8 23.3 10.70 4000
MPL-B540K 460 14.5 177.3 2660 5.40 8 42.4 19.40 4000
MPL-B560F 460 14.5 130.7 1960 5.50 8 42.4 26.80 3000
MPL-B580F 460 18.4 132.7 1990 7.10 8 66.5 34.00 3000
MPL-B580J 460 22.6 148.0 2220 7.90 8 66.5 34.00 3800
MPL-B640F 460 22.7 106.0 1590 6.11 8 46.0 36.70 3000
MPL-B660F 460 27.2 81.3 1220 6.15 8 67.9 48.00 3000
MPL-B680D 460 24.0 94.0 1410 9.30 8 66.5 62.80 2000
MPL-B680F 460 33.9 79.3 1190 7.50 8 67.9 60.00 3000
MPL-B860D 460 33.6 96.0 1440 12.50 8 67.5 83.10 2000
MPL-B880C 460 33.6 72.7 1090 12.60 8 69.0 110.00 1500
MPL-B880D 460 40.3 86.7 1300 15.00 8 113.2 110.00 2000
MPL-B960B 460 29.7 62.0 930 12.70 8 63.6 130.00 1200
MPL-B960C 460 38.9 76.0 1140 14.80 8 88.4 124.30 1500
MPL-B960D 460 50.2 76.7 1150 15.00 8 102.5 124.30 2000
MPL-B980B 460 31.8 59.3 890 15.02 8 70.7 162.70 1000
Table 4 - Motor Name Plate and Rating Specifications (Continued)
Model Number
Motor NP Volts
[line to line V rms]
Motor NP Amps
[A rms]
Motor NP
Hertz [Hz]
Motor NP RPM
[oper. rpm]
Motor NP
Power [kW]
Motor
Poles
Current peak
[A rms]
System Cont. Stall
Torque [N•m]
Motor Max RPM
[rpm]
