Rockwell Automation Publication 750-PM101B-EN-P - April 2022 121
Appendix A Permanent Magnet Motors
MPL-B980C 460 48.2 67.3 1010 16.80 8 99.0 158.20 1500
MP
L-B980D 460 63.6 74.7 1120 18.60 8 141.4 158.20 2000
MPG-A004-031 230 1.8 222.7 3340 0.21 8 4.0 0.60 6000
MPG-A010-031 230 2.1 189.3 2840 0.36 8 6.0 1.21 4875
MPG-A010-091 230 0.9 295.3 4430 0.19 8 2.3 0.41 5900
MPG-A025-031 230 9.9 181.0 1810 0.88 12 19.8 4.65 5200
MPG-A025-091 230 3.0 168.0 1680 0.52 12 8.5 2.95 5625
MPG-A050-031 230 24.7 120.0 1200 1.50 12 53.0 11.90 2510
MPG-A050-091 230 5.0 275.0 2750 0.75 12 15.6 2.60 3775
MPG-A110-031 230 20.2 122.0 1220 2.20 12 53.0 17.20 2875
MPG-A110-091 230 17.0 184.0 1840 1.60 12 33.2 8.30 3500
MPG-B010-031 460 1.6 162.7 2440 0.34 8 4.4 1.33 6450
MPG-B010-091 460 0.7 357.3 5360 0.23 8 1.5 0.41 6450
MPG-B025-031 460 4.0 219.0 2190 0.92 12 11.3 4.02 4838
MPG-B025-091 460 1.9 175.0 1750 0.54 12 5.2 2.95 5900
MPG-B050-031 460 16.3 92.0 920 1.20 12 32.5 12.40 2510
MPG-B050-091 460 3.4 290.0 2900 0.79 12 9.9 2.60 4560
MPG-B110-031 460 12.9 112.0 1120 2.00 12 31.1 17.00 2420
MPG-B110-091 460 10.6 184.0 1840 1.60 12 20.5 8.30 3500
1326AB-B410G 460 2.5 118.0 3540 1.00 4 7.4 2.70 5000
1326AB-B410J 460 3.5 165.0 4950 1.40 4 10.4 2.70 7250
1326AB-B420E 460 2.8 70.0 2100 1.10 4 8.5 5.00 3000
1326AB-B420H 460 5.5 137.3 4120 2.20 4 15.6 5.10 6000
1326AB-B430E 460 3.9 67.7 2030 1.40 4 11.7 6.60 3000
1326AB-B430G 460 5.6 114.3 3430 2.30 4 16.8 6.40 5000
1326AB-B515E 460 6.1 70.3 2110 2.30 4 18.3 10.40 3000
1326AB-B515G 460 9.5 88.7 2660 2.90 4 28.5 10.40 5000
1326AB-B520E 460 6.7 71.0 2130 2.90 4 20.1 13.00 3000
1326AB-B520F 460 8.8 70.3 2110 2.90 4 26.4 13.10 3500
1326AB-B530E 460 9.5 74.3 2230 4.20 4 28.5 18.00 3000
1326AB-B720E 460 17.5 70.0 2100 6.80 4 52.5 30.90 3500
1326AB-B720F 460 27.5 117.0 3510 11.70 4 66.5 31.80 5000
1326AB-B730E 460 22.8 78.3 2350 9.60 4 66.5 39.00 3350
1326AB-B740C 460 20.9 52.3 1570 8.70 4 62.7 53.00 2200
1326AB-B740E 460 32.0 79.7 2390 12.70 4 66.5 50.80 3400
1326AS-B310H 460 0.8 204.5 4090 0.30 6 2.4 0.70 6200
1326AS-B330H 460 2.1 204.5 4090 0.90 6 6.0 2.10 6500
1326AS-B420G 460 2.6 179.0 3580 1.20 6 7.8 3.20 5250
1326AS-B440G 460 5.4 149.0 2980 2.00 6 16.2 6.40 5250
1326AS-B460F 460 6.2 148.5 2970 2.80 6 18.6 9.00 4300
1326AS-B630F 460 7.8 142.7 2140 2.40 8 18.5 10.70 4500
1326AS-B660E 460 11.8 100.7 1510 3.40 8 29.8 21.50 3000
1326AS-B690E 460 19.0 87.3 1310 5.00 8 41.3 36.40 3000
1326AS-B840E 460 21.2 79.3 1190 4.70 8 39.5 37.60 3000
1326AS-B860C 460 17.6 77.3 1160 6.00 8 44.4 49.30 2000
1326AH-B330F 460 2.1 0.0 3000 0.75 - 9.0 - 3000
1326AH-B440F 460 3.3 0.0 2500 1.22 - 13.8 - 2500
1326AH-B540F 460 11.1 0.0 2500 2.60 - 47.2 - 2500
3050R-7 390 66.0 50.0 500 30.00 12 132.0 - 500
11050R-7 390 218.0 50.0 500 110.00 12 436.0 - 500
Table 4 - Motor Name Plate and Rating Specifications (Continued)
Model Number
Motor NP Volts
[line to line V rms]
Motor NP Amps
[A rms]
Motor NP
Hertz [Hz]
Motor NP RPM
[oper. rpm]
Motor NP
Power [kW]
Motor
Poles
Current peak
[A rms]
System Cont. Stall
Torque [N•m]
Motor Max RPM
[rpm]
