Figure 4.3 - Motor Stops While Running
Symptom Possible Causes Remedy
“CONTROL
VOLTAGE” LED On
• Mechanical problems
• Pilot devices
• Failed control module
• Check for binding or external loading and correct
• Check for normal “stop” operation
• Replace control module
“CONTROL
VOLTAGE” LED Off
• Control voltage not present
• Overload trip
• Failed control module
• Check for correct control voltage
• Check overload relay and heater element selection
• Replace control module
“START”
LED On
• Open gate circuitry • Perform resistance check; replace power module if necessary
“STALL”
LED On
• Motor rotor locked
• Stall select switch set incorrectly
• Correct source of stall
• Check DIP switch #3 for correct setting
• Set stall feature off (DIP switch #3 to OFF) then attempt to start
motor
• Failed control module • Replace control module
“TEMP” LED On
• Controller ventilation blocked
• Motor overloaded
• Controller duty cycle exceeded
• Fan failure (if used)
• Ambient temperature limit exceeded
• Failed Thermister
• Failed control module
• Check for proper ventilation
• Correct motor overload condition
• Check application duty cycle
• Check for correct fan operation, replace if necessary
• Wait for controller to cool or provide external cooling
• Replace Power Pole
• Replace control module
“LINE” LED On
• Open line condition
• Motor not connected properly
• Shorted SCR
• Failed control module
• Check for open line (e.g., blown line fuse)
• Check for open load lead
• Check for shorted SCR, replace if necessary
• Replace control module
