Rockwell Automation Publication 520-UM001I-EN-E - July 2016 127
Programming and Parameters Chapter 3
Advanced Program Group (continued)
A502 [PM IXd Voltage]
PowerFlex 525 only.
(With FRN 5.xxx and later.)
Voltage across the d-axis stator inductance of the PM motor at the rated motor current and the rated motor frequency displayed in line-to-line rms value.
Values Default: 17.91V
Min/Max: 0.00/655.35V
Display: 0.01V
PF 525
A503 [PM IXq Voltage]
PowerFlex 525 only.
(With FRN 5.xxx and later.)
Voltage across the q-axis stator inductance of the PM motor at the rated motor current and the rated motor frequency displayed in line-to-line rms value.
Values Default: 53.21V
Min/Max: 0.00/655.35V
Display: 0.01V
PF 525
A504 [PM BEMF Voltage]
PowerFlex 525 only.
(With FRN 5.xxx and later.)
Back electromotive force (EMF) voltage.
Values Default: 1640.0 Drive Rated Volts
Min/Max: 0.0/6000.0 Drive Rated Volts
Display: 0.1V
PF 525
A509 [Speed Reg Sel] Related Parameter(s): A521, A522, A523, A524, A525, A526
PowerFlex 525 only.
Determines if PI gain of the “Vector” control mode speed regulator is set automatically or manually. Parameters A521...A526 are set automatically by this parameter.
Options 0 “Automatic” (Default)
1“Manual”
PF 525
A510 [Freq 1]
A512 [Freq 2]
A514 [Freq 3]
PowerFlex 525 only.
Sets the “Vector” control mode frequency.
Values Default:
Freq 1:
Freq 2:
Freq 3:
8.33%
15.00%
20.00%
Min/Max: 0.00/200.00%
Display: 0.01%
PF 525
