Rockwell Automation Publication 520-UM001I-EN-E - July 2016 115
Programming and Parameters Chapter 3
Advanced Program Group
A410 [Preset Freq 0]
A412 [Preset Freq 2]
A414 [Preset Freq 4]
A416 [Preset Freq 6]
A411 [Preset Freq 1]
A413 [Preset Freq 3]
A415 [Preset Freq 5]
A417 [Preset Freq 7]
A418 [Preset Freq 8]
A420 [Preset Freq 10]
A422 [Preset Freq 12]
A424 [Preset Freq 14]
PowerFlex 525 only.
A419 [Preset Freq 9]
A421 [Preset Freq 11]
A423 [Preset Freq 13]
A425 [Preset Freq 15]
Sets the frequency of the drive outputs to the programmed value when selected.
Values Defaults:
Preset Freq 0:
Preset Freq 1:
Preset Freq 2:
Preset Freq 3:
Preset Freq 4:
Preset Freq 5:
Preset Freq 6:
Preset Freq 7...15:
0.00 Hz
5.00 Hz
10.00 HZ
20.00 Hz
30.00 Hz
40.00 Hz
50.00 Hz
60.00 Hz
Min/Max: 0.00/500.00 Hz
Display: 0.01 Hz
PF 525
For PowerFlex 525
Default Accel/Decel Used Preset Input 1
(DigIn TermBlk 05)
Preset Input 2
(DigIn TermBlk 06)
Preset Input 3
(DigIn TermBlk 07)
Preset Input 4
(DigIn TermBlk 08)
Preset Setting 0
(1)
(1) Preset Setting 0 is only available if P047, P049 or P051 [Speed Referencex] is set to 7 “Preset Freq”.
10000
Preset Setting 1 1 1 0 0 0
Preset Setting 2 2 0 1 0 0
Preset Setting 3 2 1 1 0 0
Preset Setting 4 1 0 0 1 0
Preset Setting 5 1 1 0 1 0
Preset Setting 6 2 0 1 1 0
Preset Setting 7 2 1 1 1 0
Preset Setting 8 1 0 0 0 1
Preset Setting 9 1 1 0 0 1
Preset Setting 10 2 0 1 0 1
Preset Setting 11 2 1 1 0 1
Preset Setting 12 1 0 0 1 1
Preset Setting 13 1 1 0 1 1
Preset Setting 14 2 0 1 1 1
Preset Setting 15 2 1 1 1 1
For PowerFlex 523
Default Accel/Decel Used Preset Input 1
(DigIn TermBlk 05)
Preset Input 2
(DigIn TermBlk 06)
Preset Input 3
(DigIn TermBlk 03)
–
Preset Setting 0
(1)
1000
–
Preset Setting 1 1 1 0 0
Preset Setting 2 2 0 1 0
Preset Setting 3 2 1 1 0
Preset Setting 4 1 0 0 1
Preset Setting 5 1 1 0 1
Preset Setting 6 2 0 1 1
Preset Setting 7 2 1 1 1
