Appendix B Accessories and Dimensions
200...240V
50/60 Hz
1-Phase
0.25 0.2 1.6 A 25-RF011-AL
0.5 0.4 2.5 A 25-RF011-AL
1.0 0.75 4.8 A 25-RF011-AL
2.0 1.5 8.0 B 25-RF023-BL
3.0 2.2 11.0 B 25-RF023-BL
200...240V
50/60 Hz
3-Phase
0.25 0.2 1.6 A 25-RF014-AL
0.5 0.4 2.5 A 25-RF014-AL
1.0 0.75 5.0 A 25-RF014-AL
2.0 1.5 8.0 A 25-RF014-AL
3.0 2.2 11.0 A 25-RF014-AL
5.0 4.0 17.5 B 25-RF021-BL
7.5 5.5 24.0 C 25-RF027-CL
10.0 7.5 32.2 D 25-RF035-DL
15.0 11.0 48.3 E 25-RF056-EL
20.0 15.0 62.1 E 25-RF056-EL
380...480V
50/60 Hz
3-Phase
0.5 0.4 1.4 A 25-RF7P5-AL
1.0 0.75 2.3 A 25-RF7P5-AL
2.0 1.5 4.0 A 25-RF7P5-AL
3.0 2.2 6.0 A 25-RF7P5-AL
5.0 4.0 10.5 B 25-RF014-BL
7.5 5.5 13.0 C 25-RF018-CL
10.0 7.5 17.0 C 25-RF018-CL
15.0 11.0 24.0 D 25-RF033-DL
20.0 15.0 30.0 D 25-RF033-DL
25.0 18.5 37.0 E 25-RF039-EL
30.0 22.0 43.0 E 25-RF039-EL
(1)
525...600V
50/60 Hz
3-Phase
0.5 0.4 0.9 A 25-RF8P0-BL
(2)
1.0 0.75 1.7 A 25-RF8P0-BL
(2)
2.0 1.5 3.0 A 25-RF8P0-BL
(2)
3.0 2.2 4.2 A 25-RF8P0-BL
(2)
5.0 4.0 6.6 B 25-RF8P0-BL
7.5 5.5 9.9 C 25-RF014-CL
10.0 7.5 12.0 C 25-RF014-CL
15.0 11.0 19.0 D 25-RF027-DL
20.0 15.0 22.0 D 25-RF027-DL
25.0 18.5 27.0 E 25-RF029-EL
30.0 22.0 32.0 E 25-RF029-EL
(1)
(1) EMC Line Filter size is based on the input current of the drive. See the tables on page 26 and page 27 for more information.
(2) This 600V drive rating needs to be matched with a frame B EMC Line Filter.
EMC Line Filters
Short Circuit Current Rating = 100 kA
Drive Ratings
Frame Size Catalog No.Input Voltage HP kW Current (A)
