180 Rockwell Automation Publication 520-UM001I-EN-E - July 2016
Appendix B Accessories and Dimensions
Replacement Parts
Bulletin 160 to PowerFlex 520-Series Mounting Adapter Plate
Item Description
B160
Frame
Size Catalog No.
Mounting Adapter Plate For use with drive when replacing Bulletin 160 drives in
existing installations to a PowerFlex 520-Series drive. Select
the catalog number based on the frame size of your Bulletin
160 drive.
A 25-MAP-FA
B 25-MAP-FB
PowerFlex 520-Series Power Module
Item Description
PowerFlex 520-Series
Power Module
Replacement power module for use with PowerFlex 520-Series drives. Includes:
• Power Module
• Power Module Front Cover
• Power Terminal Guard
• Heatsink Fan
Output Ratings
Input
Voltage Range
Frame
Size Catalog No.
Normal Duty Heavy Duty
Output
Current (A)HP kW HP kW
100...120V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 85...132 A 25-PM1-V1P6
0.5 0.4 0.5 0.4 2.5 85...132 A 25-PM1-V2P5
1.0 0.75 1.0 0.75 4.8 85...132 B 25-PM1-V4P8
1.5 1.1 1.5 1.1 6.0 85...132 B 25-PM1-V6P0
200...240V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25-PM1-A1P6
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM1-A2P5
1.0 0.75 1.0 0.75 4.8 170...264 A 25-PM1-A4P8
2.0 1.5 2.0 1.5 8.0 170...264 B 25-PM1-A8P0
3.0 2.2 3.0 2.2 11.0 170...264 B 25-PM1-A011
200...240V AC (-15%, +10%) – 1-Phase Input with EMC Filter, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25-PM2-A1P6
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM2-A2P5
1.0 0.75 1.0 0.75 4.8 170...264 A 25-PM2-A4P8
2.0 1.5 2.0 1.5 8.0 170...264 B 25-PM2-A8P0
3.0 2.2 3.0 2.2 11.0 170...264 B 25-PM2-A011
200...240V AC (-15%, +10%) – 3-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25-PM1-B1P6
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM1-B2P5
1.0 0.75 1.0 0.75 5.0 170...264 A 25-PM1-B5P0
2.0 1.5 2.0 1.5 8.0 170...264 A 25-PM1-B8P0
3.0 2.2 3.0 2.2 11.0 170...264 A 25-PM1-B011
5.0 4.0 5.0 4.0 17.5 170...264 B 25-PM1-B017
7.5 5.5 7.5 5.5 24.0 170...264 C 25-PM1-B024
10.0 7.5 10.0 7.5 32.2 170...264 D 25-PM1-B032
15.0 11.0 10.0 7.5 48.3 170...264 E 25-PM1-B048
20.0 15.0 15.0 11.0 62.1 170...264 E 25-PM1-B062
380...480V AC (-15%, +10%) – 3-Phase Input, 0...460V 3-Phase Output
0.5 0.4 0.5 0.4 1.4 323...528 A 25-PM1-D1P4
