182 Rockwell Automation Publication 520-UM001I-EN-E - July 2016
Appendix B Accessories and Dimensions
PowerFlex 520-Series
Power Module Front Cover
Replacement cover for the PowerFlex 520-Series power
module.
B 25-PMFC-FB
C 25-PMFC-FC
D 25-PMFC-FD
E 25-PMFC-FE
PowerFlex 520-Series
Power Terminal Guard
Replacement finger guard for power terminals. A 25-PTG1-FA
B 25-PTG1-FB
C 25-PTG1-FC
D 25-PTG1-FD
E 25-PTG1-FE
PowerFlex 520-Series
Heatsink Fan Kit
Replacement fan for drive power module. A 25-FAN1-FA
B 25-FAN1-FB
C 25-FAN1-FC
D 25-FAN1-FD
E 25-FAN1-FE
PowerFlex 520-Series EMC
Cores
Replacement EMC cores A 25-CORE-A
25-CORE-RF-A
B 25-CORE-B
25-CORE-RF-B
C 25-CORE-C
25-CORE-RF-C
D 25-CORE-D
25-CORE-RF-D
E 25-CORE-E
25-CORE-RF-E
Communication Option Kits and Accessories
Item Description Catalog No.
Communication Adapters Embedded communication options for use with the
PowerFlex 520-Series drives:
• DeviceNet™
• Dual Port EtherNet/IP™
• PROFIBUS™ DP-V1
25-COMM-D
25-COMM-E2P
25-COMM-P
Compact I/O Module Three channel 1769-SM2
Universal Serial Bus™ (USB)
Converter Module
Provides serial communication with DF1 protocol for use with
Connected Components Workbench software. Includes:
• 2 m USB cable (1)
• 20-HIM-H10 cable (1)
• 22-HIM-H10 cable (1)
1203-USB
Serial Converter Module
(RS485 to RS232)
Provides serial communication with DF1 protocol for use with
Connected Components Workbench software. Includes:
• DSI to RS232 serial converter (1)
• 1203-SFC serial cable (1)
• 22-RJ45CBL-C20 cable (1)
22-SCM-232
DSI Cable 2.0 m RJ45 to RJ45 cable, male to male connectors. 22-RJ45CBL-C20
Serial Cable 2.0 m serial cable with a locking low profile connector to
connect to the serial converter and a 9-pin sub-miniature D
female connector to connect to a computer.
1203-SFC
Splitter Cable RJ45 one to two port splitter cable (Modbus only) AK-U0-RJ45-SC1
Other Parts
Item Description
Frame
Size Catalog No.
