Rockwell Automation Publication 520-UM001I-EN-E - July 2016 189
Accessories and Dimensions Appendix B
IP 20/Open Type with Control Module Fan Kit – Frame D...E
Esc
Sel
130.0 (5.12)
32.0 (1.26)
260.0 (10.24)
247.0 (9.72)
116.0 (4.57)
Esc
Sel
185.0 (7.28)
196.0 (7.72)
52.0 (2.05)
300.0 (11.81)
280.0 (11.02)
160.0 (6.30)
Dimensions are in millimeters and (inches)
Frame D Frame E
IMPORTANT
Remove the label to access the built-in 24V supply on drive frames D and E for use with the
Control Module Fan Kit.
