88 Rockwell Automation Publication 520-UM001I-EN-E - July 2016
Chapter 3 Programming and Parameters
Basic Program Group (continued)
P053 [Reset To Defalts]
Stop drive before changing this parameter.
Resets all parameters to their factory default values. After a Reset command, the value of this parameter returns to zero.
Options 0 “Ready/Idle” (Default)
1 “Param Reset” Does not reset custom groups, parameter P030 [Language], and communication parameters.
2 “Factory Rset” Restore drive to factory condition.
3 “Power Reset” Resets only power parameters. Can be used when swapping power modules.
4 “Module Reset”
(1)
(2)
Power cycle of the drive, NO parameters are reset.
(1) Setting is available in PowerFlex 525 FRN 5.xxx and later.
(2) Setting is available in PowerFlex 523 FRN 3.xxx and later.
Parameters that are Reset when P053 = 3
Parameter Name
P031 [Motor NP Volts]
P033 [Motor OL] Current
P034 [Motor NP FLA]
P035 [Motor NP Poles]
P038 [Voltage Class]
A435 [DC Brake Level]
A484 [Current Limit 1]
A485 [Current Limit 2]
A486 [Shear Pin1 Level]
A488 [Shear Pin2 Level]
A490 [Load Loss Level]
A496 [IR Voltage Drop]
A497 [Flux Current Ref]
A530 [Boost Select]
A531 [Start Boost]
A532 [Break Voltage]
A533 [Break Frequency]
A534 [Maximum] Voltage
Parameters that are NOT Reset when P053 = 1
Parameter Parameter Parameter
P030 [Language] C138 [EN Gateway Cfg 2] C159 [EN Data Out 3]
C121 [Comm Write Mode] C139 [EN Gateway Cfg 3] C160 [EN Data Out 4]
C122 [Cmd Stat Select] C140 [EN Gateway Cfg 4] C161 [Opt Data In 1]
C123 [RS485 Data Rate] C141 [EN Rate Cfg] C162 [Opt Data In 2]
C124 [RS485 Node Addr] C143 [EN Comm Flt Actn] C163 [Opt Data In 3]
C124 [Comm Loss Action] C144 [EN Idle Flt Actn] C164 [Opt Data In 4]
C126 [Comm Loss Time] C145 [EN Flt Cfg Logic] C165 [Opt Data Out 1]
C127 [RS485 Format] C146 [EN Flt Cfg Ref] C166 [Opt Data Out 2]
C128 [EN Addr Sel] C147 [EN Flt Cfg DL 1] C167 [Opt Data Out 3]
C129 [EN IP Addr Cfg 1] C148 [EN Flt Cfg DL 2] C168 [Opt Data Out 4]
C130 [EN IP Addr Cfg 2] C149 [EN Flt Cfg DL 3] C169 [MultiDrv Sel]
C131 [EN IP Addr Cfg 3] C150 [EN Flt Cfg DL 4] C171 [Drv 1 Addr]
C132 [EN IP Addr Cfg 4] C153 [EN Data In 1] C172 [Drv 2 Addr]
C133 [EN Subnet Cfg 1] C154 [EN Data In 2] C173 [Drv 3 Addr]
C134 [EN Subnet Cfg 2] C155 [EN Data In 3] C174 [Drv 4 Addr]
C135 [EN Subnet Cfg 3] C156 [EN Data In 4] C175 [DSI I/O Cfg]
C136 [EN Subnet Cfg 4] C157 [EN Data Out 1] GC [Parameters in Custom Group]
C137 [EN Gateway Cfg 1] C158 [EN Data Out 2]
