PowerFlex 40 Standard Configured Drive Standard Features and Options 1-5
Publication 23B-IN001G
Drive Input Fused Disconnect Switch (Position 16+, Code -P6)
The Drive Input Fused Disconnect Switch option is factory installed and
provides a manual means of disconnecting input power to the drive. The
Allen-Bradley Bulletin 194R switch is designed to meet disconnect switch
requirements for branch circuit protection. The rotary style handle is
padlockable in On or Off position. This option has a 100 kA short circuit
withstand rating. Class J fuses are supplied with the disconnect switch.
Incoming customer supplied power cables terminate at terminals R, S, T
(L1, L2, L3) located on the bottom of the device.
Component Specifications
Drive Input Fused Disconnect Switch (Position 16+, Code -P6T)
The Drive Input Fused Disconnect Switch option is factory installed and
provides a manual means of disconnecting input power to the drive. The
Allen-Bradley Bulletin 194R switch is designed to meet disconnect switch
requirements for branch circuit protection. The rotary style handle is
padlockable in On or Off position. This option has a 100 kA short circuit
withstand rating. Class J fuses are supplied with the disconnect switch.
Incoming customer supplied power cables terminate at terminals R, S, T
(L1, L2, L3) located on the top of the device.
Component Specifications
Switch A-B Bulletin 194R, 600V, 100 kA short circuit withstand rating
Integral class J fuses, Captive terminal clamps
3-pole, Rod operated
UL listed, CE Approved, CSA, ASTA, and LOVAG Certified
Handle Rotary style handle through the door, Door interlocked
Padlockable in On or Off position, Defeatable in the On position
True switch status indication
IP66 (Type 3R, 3, 12, 4, 4X)
Switch A-B Bulletin 194R, 600V, 100 kA short circuit withstand rating
Integral class J fuses, Captive terminal clamps
3-pole, Rod operated
UL listed, CE Approved, CSA, ASTA, and LOVAG Certified
Handle Rotary style handle through the door, Door interlocked
Padlockable in On or Off position, Defeatable in the On position
True switch status indication
IP66 (Type 3R, 3, 12, 4, 4X)
