Publication 23B-IN001G
Appendix A
Specifications
Table A.A Standard Configured Drive Products
Table A.B Standard PowerFlex 40 Drives
Input/Output Ratings Output Frequency: 0-400 Hz (Programmable)
Efficiency: 97.5% (Typical)
Approvals
Fuses and Power
Disconnecting Means
140M Motor Circuit Protector: Provides branch circuit protection, 65 kA short circuit withstand
194R Fused Disconnect: Provides branch circuit protection, 100 kA short circuit withstand, Class J fuses
Protective Features Over Voltage: 480V AC Input – Trip occurs at 810V DC bus voltage (equivalent to 575V AC incoming line)
Under Voltage: 480V AC Input – Trip occurs at 390V DC bus voltage (equivalent to 275V AC incoming line)
Environment Ambient Operating Temperature, NEMA 4/12, 4X (IP66): –10 to 40 degrees C (14 to 104 degrees F)
(1)
Cooling Method: Fan (All drive ratings)
(1) The design of the PowerFlex 40 Standard Configured Drive NEMA 4/12 and 4X packages support indoor and outdoor applications that are not in direct sunlight.
When optional Door Mounted HIM is supplied, enclosure is rated for indoor use only.
Control Carrier Frequency: 2-4 kHz. Drive rating and heat calculations are based on 4 kHz.
Digital Control Inputs
(Input Current = 6 mA)
SRC (Source) Mode: 18 – 24 Volts = ON; 0 – 6 Volts = OFF
SNK (Sink) Mode: 0 – 6 Volts = ON; 18 – 24 Volts = OFF
Analog Control Inputs 4-20mA Analog: 250 ohm input impedance
0-10V DC Analog: 100k ohm input impedance
External Pot: 1-10k ohms, 2 Watt minimum
Control Output Programmable Output (form C relay)
Resistive Rating: 3.0A at 30V DC, 3.0A at 125V AC, 3.0A at 240V AC
Inductive Rating: 0.5A at 30V DC, 0.5A at 125V AC, 0.5A at 240V AC
Opto Outputs
30V DC, 50 mA
Non-inductive
Analog Output (10-bit)
0-10V, 1k ohm Min.
Fuses and Circuit Breakers Recommended Fuse Type: UL Class J, CC, T or Type BS88; 600V (550V) or equivalent.
Recommended Circuit Breakers: HMCP circuit breaker or equivalent.
Protective Features Motor Protection: I
2
t overload protection – 150% for 60 Secs, 200% for 3 Secs (Provides Class 10 protection)
Overcurrent: 200% hardware limit, 300% instantaneous fault
Control Ride Through: Minimum ride through is 0.5 Secs - typical value 2 Secs
Faultless Power Ride Through: 100 milliseconds
Dynamic Braking Internal brake IGBT included with all ratings
Environment Altitude: 1000 m (3300 ft) max. without derating
Storage Temperature: –40 to 85 degrees C (–40 to 185 degrees F)
Atmosphere: Important: Drive must not be installed in an area where the ambient atmosphere contains
volatile or corrosive gas, vapors or dust. If the drive is not going to be installed for a period of
time, it must be stored in an area where it will not be exposed to a corrosive atmosphere.
Relative Humidity: 0 to 95% non-condensing
Shock (operating): 15G peak for 11ms duration (±1.0ms)
Vibration (operating): 1G peak, 5 to 2000 Hz
Control Frequency Accuracy
Digital Input: Within ±0.05% of set output frequency.
Analog Input: Within 0.5% of maximum output frequency.
Analog Output: ±2% of full scale, 10-bit resolution
Speed Regulation - Open Loop with Slip Compensation: ±2% of base speed across a 40:1 speed range.
1% of base speed across a 60:1 speed range.
Stop Modes: Multiple programmable stop modes including - Ramp, Coast, DC-Brake, Ramp-to-Hold and S Curve.
Accel/Decel: Two independently programmable accel and decel times. Each time may be programmed from 0 -
600 seconds in 0.1 second increments.
Intermittent Overload: 150% Overload capability for up to 1 minute; 200% Overload capability for up to 3 seconds
Electronic Motor Overload Protection: Class 10 protection with speed sensitive response.
U
L
®
L
I
S
T
E
D
9
6
6
X
I
N
D
C
O
N
T
E
Q
UL508C
U
L
®
L
I
S
T
E
D
9
6
6
X
I
N
D
C
O
N
T
E
Q
C
CSA C 22.2 No. 14
