Publication 23B-IN001G
Chapter 1
PowerFlex 40 Standard Configured Drive
Standard Features and Options
Chapter Objectives
This chapter describes the standard features and operation for PowerFlex 40
Standard Configured Drives and associated options.
Standard Features
This package integrates the Standard PowerFlex 40 drive. The PowerFlex
40 drive can be used for Volts per hertz or Sensorless Vector applications
and offers an Autotune feature allowing the drive to adapt to individual
motor characteristics.
The PowerFlex 40 is assembled in an enclosure which includes the
following features…
• NEMA/UL Type 4/4X - indoor and outdoor applications other than
direct sunlight.
(1)
• Flange mount drive/external heatsink reducing overall enclosure size.
• Mounting feet - orientation is adjustable per customer requirements.
If required, the drive can be removed from the front of the enclosure for
ease of assembly or repair.
Low cost, highly configurable I/O inputs and/or 0-10V/4-20 mA outputs
that are not used by program standard features and options are available for
customer use.
For information on … See page …
Standard Features
1-1
Enclosure Options 1-2
Communication Options 1-3
Power Disconnect Options 1-4
Operator Device Options 1-9
Quick Disconnects 1-15
I/O Options 1-16
(1)
The enclosure does not normally protect electrical equipment from
condensation, corrosion or contamination, which may occur within the
enclosure or enter via the conduit or unsealed openings. Users must
make adequate provisions to safeguard against such conditions, and
satisfy themselves that the equipment is properly protected. For further
information on criteria associated with NEMA enclosure ratings, refer to
NEMA standards Publication No. 250-1991. When optional Door
Mounted HIM is supplied, enclosure is rated indoor only. See enclosure
options for specific enclosure style quoted.
