1-4 PowerFlex 40 Standard Configured Drive Standard Features and Options

Publication 23B-IN001G

Power Disconnect Options

Drive Motor Circuit Protector (Position 16+, Code -P3)

The Drive Motor Circuit Protector option is factory installed and provides a

manual means of disconnecting input power to the drive. The Allen-Bradley

Bulletin 140M switch is designed to meet short circuit requirements for

branch circuit protection. The rotary style handle is padlockable in On or

Off position. This option has a 65 kA short circuit withstand rating. Over

load protection is supplied by the drive not the motor circuit protector.

Incoming customer supplied power cables terminate at terminals R, S, T

(L1, L2, L3) located on the bottom of the device.

Component Specifications

Drive Motor Circuit Protector (Position 16+, Code -P3T)

The Drive Motor Circuit Protector option is factory installed and provides a

manual means of disconnecting input power to the drive. The Allen-Bradley

Bulletin 140M switch is designed to meet short circuit requirements for

branch circuit protection. The rotary style handle is padlockable in On or

Off position. This option has a 65 kA short circuit withstand rating. Over

load protection is supplied by the drive not the motor circuit protector.

Incoming customer supplied power cables terminate at terminals R, S, T

(L1, L2, L3) located on the top of the device.

Component Specifications

Switch A-B Bulletin 140M, 480V, 65 kA short circuit withstand rating

3-pole, Rod operated

UL listed, CE Approved, CSA Certified

Handle Rotary style handle through the door, Door interlocked

Padlockable in On or Off position, Defeatable in the On position

IP66 (Type 3R, 3, 12, 4, 4X)
