Tools & Prerequisites
Software programs required
• Studio 5000 Logix Designer v28.00
• PowerFlex 525 Add-On Profile v1.04.00
• PowerFlex 755 Add-On Profile v4.08.00
• Connected Components Workbench v8.01
• RSLinx Classic v3.74.00
• FactoryTalk View Studio v8.10
• RSLinx Enterprise v5.74.00
• Wizards v3.14.3
Hardware devices required
• PowerFlex 525/527 Demo Box (PF52X1)
o CompactLogix 5370 Controller (1769-L18ERM-BB1B) – v28.011.20
o 1738-ETAP
o PowerFlex 525 AC Drive (25B-V2P5N104) – v4.001, with 25-COMM-E2P Option module
• PowerFlex 755 DHQ Demo Box (PN-39023)
o PowerFlex 755 AC Drive (20G11-N-B-DM1AA6K32V8) – v12.001
• Ethernet patch cables
Files required
• PowerFlex_Lab.ACD
• PowerFlex_Lab_ADC.ACD
• PowerFlex.mer
Lab files are located within the “C:\Users\labuser\Desktop\Lab Files\PF525 and PF755 - Basic HIM,
CCW, PI\Lab Files” folder.
