Click Next
to get to the Motor Data step of the wizard.
32. The Motor Data step is next. This step assists in entering the data from your motor’s nameplate into the drive.
Change the parameters to the following:
 Power Units: HP
 Motor NP Power: 0.03 HP
 Motor NP FLA: 0.22 Amps
 Motor NP Volts: 230 VAC
 Motor NP Hertz: 60 Hz
 Motor NP RPM: 1600 RPM
 Motor OL Factor: 1.00
 Motor Poles: 4 Pole
