118 Rockwell Automation Publication 750-TG100B-EN-P - June 2019
Chapter 6 Frame 7 Components
14. For the motor side inverter module, remove the six M8 x 30 mm torx
screws that secure the AC output flexible bus bars to the AC output
terminals on the power module, and remove the flexible bus bars.
14
M8 x 30 mm
T40
19.8 N•m (175 lb•in)
To Next Page
