Control Bay and Control Pod Components Chapter 7
19. Loosen the three captive thumb screws that secure the main control board
to the pod chassis and remove the board.
19
–
T15 or F - 5 mm (0.19 in.)
0.45 N•m (4 lb•in)
HIM Bezel Not Shown for Clarity Only.
19
=
