Rockwell Automation Publication 750-TG100B-EN-P - June 2019 185

Input Bay Components Chapter 8

Frames 10…15 Input Bay (Frame 10 Shown)

4

M5.5 x 13 mm

T25

2.6 N

•m (23 lb•in)

=
