246 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 9 Power Bay Components

6. Disconnect the cable connector P13 from connector J13 on the power

layer interface circuit board.

CTL

2

+

+

J13

4

3

1

PDI

=
