266 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 9 Power Bay Components

5. Remove the wire access cover to more easily feed the wiring through the

back of the chassis when a capacitor assembly is removed. Remove the

eight M4 x 10 mm torx screws that secure the capacitor wire access cover to

the chassis and remove the cover.

M4 x 10 mm

T25

3 N•m (26 lb•in)
