284 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 10 Wire Entry/Exit Bay Components

Figure 23 - Wire Entry/Exit Bay Kits Identification

2

1

3

1

1

800 mm Wide Wire Entry/Exit Bay Shown
